CONNECT AND DISCONNECT THE CHARGER TO A BATTERY
The MXS 5.0 comes with automatic temperature compensation for the best charging performance, even in extreme conditions. The MXS 5.0 is an advanced microprocessor controlled battery charger which gives unrivalled performance for lead acid batteries from 1.2-110Ah. CTEK MXS 5.0 User Manual. Comfort connect, Connect and disconnect the charger to a battery. CTEK Power suppliers Manuals Directory ManualsDir.com - online owner manuals library Search.
INFO
MXS 5.0 CONGRATULATIONS to the purchase of your new professional switch mode battery charger. This charger is included in a series of professional chargers from CTEK SWEDEN AB and represents the latest technology in battery charging. CTEK COMFORT CONNECT – eyelet M6 MODE RECOND 12V/5A MXS 5.0 CTEK COMFORT CONNECT MAINS CABLE CTEK COMFORT. Page 6 Trouble Shooting Guide MXS 5.0, MXS 5.0 CHECK, MXS 5.0 Polar, MXS 4003 No LED is lit when the charger is connected only to the battery. Explanation: The plug has to be connected for the LED’s to be lit. No LED is lit when the charger is connected only to the power outlet.
If the battery clamps are incor-
rectly connected, the reverse
Get your user manual by e-mail Enter your email address to receive the manual of Ctek MXS 5.0 in the language / languages: German as an attachment in your email. The manual is 1,73 mb in size. Nov 15, 2012 CTEK MXS 5.0 Car Battery Charger Unboxing and Battery Replacement - Duration: 30:56. Nonsensical Child 13,389 views. AWESOME IDEA! HOW TO TWIST ELECTRIC WIRE TOGETHER! View and Download CTEK MXS 7.0 product manual online. MXS 7.0 Battery Charger pdf manual download. Battery Charger CTEK MXS 10 User Manual. Professional charging in consumer format (2 pages). Battery Charger CTEK MXS 5.0 Manual (52 pages) Battery Charger CTEK M200 User Manual. For lead-acid batteries (7 pages).
polarity protection will ensure that
the battery and charger are not
damaged.
For batteries mounted inside a
vehicle
1. Connect the red clamp to the bat-
tery's positive pole.
2. Connect the black clamp to the
vehicle chassis remote from the fuel
pipe and the battery.
3. Connect the charger to the wall
socket
4. Disconnect the charger from the wall
socket before disconnecting the battery
5. Disconnect the black clamp before
the red clamp.
Some vehicles may have posi-
tively earthed batteries.
1. Connect the black clamp to the bat-
tery's negative pole.
2. Connect the red clamp to the vehicle
chassis remote from the fuel pipe and
the battery.
3. Connect the charger to the wall
socket
4. Disconnect the charger from the wall
socket before disconnecting the battery
5. Disconnect the red clamp before the
black clamp.
STEP 1 DESULPHATION
Detects sulphated batteries. Pulsing current and voltage, removes sulphate from the lead
plates of the battery restoring the battery capacity.
STEP 2 SOFT START
Tests if the battery can accept charge. This step prevents that charging proceeds with a
defect battery.
STEP 3 BULK
Charging with maximum current until approximately 80% battery capacity.
STEP 4 ABSORPTION
Charging with declining current to maximize up to 100% battery capacity.
STEP 5 ANALYSE
Tests if the battery can hold charge. Batteries that can not hold charge may need to be
replaced.
STEP 6 RECOND
Choose
Ctek Mxs 10
the Recond program to add the Recond step to the charging process. During the
Recond step voltage increases to create controlled gassing in the battery. Gasing mixes the
battery acid and gives back energy to the battery.
STEP 7 FLOAT
Maintaining the battery voltage at maximum level by providing a constant voltage charge.
STEP 8 PULSE
Ctek Mxs 5 Manual
Maintaining the battery at 95–100% capacity. The charger monitors the battery voltage
and gives a pulse when necessary to keep the battery fully charged.
